Support for VLESS Reverse

Предложения
1

Summary

Xray v25.10.15 (PR #5101) introduces a VLESS simplified reverse proxy feature where a specific user entry in a VLESS inbound includes a reverse field:

{
  "tag": "r-inbound",
  "port": 8443,
  "protocol": "vless",
  "settings": {
    "users": [
      {
        "id": "ac04551d-6ebf-4685-86e2-17c12491f7f4",
        "flow": "xtls-rprx-vision",
        "reverse": {
          "tag": "r-outbound"
        }
      }
    ],
    "decryption": "mlkem768x25519plus.native.600s.aCF82eKiK6g0DIbv0_nsjbHC4RyKCc9NRjl-X9lyi0k"
  }
}

This allows a device behind NAT/firewall (no inbound ports open) to establish a reverse tunnel to a public server without any overlay network such as Tailscale.

References:

Problem

Remnawave’s config processing pipeline makes this impossible for three reasons:

Issue 1: cleanInboundClients() unconditionally wipes all VLESS users/clients

In src/common/helpers/xray-config/xray-config.validator.ts:

public cleanInboundClients(injectFlow: boolean): void {
    for (const inbound of this.config.inbounds) {
        if (!this.hasManagedClients(inbound)) continue;
        this.ensureSettings(inbound);
        inbound.settings!.clients = [];  // always wiped
    }
}

Any reverse-annotated user entry written in the config profile is destroyed before xray receives the config.

Issue 2: addUsersToInbound() only injects { id, email } — no reverse field

case 'vless':
    inbound.settings.clients ??= [];
    for (const user of users) {
        inbound.settings.clients.push({
            id: user.vlessUuid,
            email: user.tId.toString(),
            // 'reverse' field is never injected
        });
    }

There is no mechanism in the user data model or squad system to carry a reverse field through to the injected config.

Issue 3: leaveInbounds() excludes unregistered VLESS inbounds

public leaveInbounds(tags: Set): void {
    this.config.inbounds = this.config.inbounds!.filter(
        (inbound) => tags.has(inbound.tag!) || !this.hasManagedClients(inbound),
    );
}

Since vless is a managed protocol, a reverse-only inbound not present in activeInbounds is stripped from the config. But if it is added to activeInbounds, its reverse-annotated users get wiped by Issue 1.

Use Case

A device sits behind a home router where the firewall cannot be modified (no open inbound ports). The VLESS simplified reverse proxy in Xray v26 is exactly designed for this NAT traversal scenario — the internal device initiates an outbound connection to the public server and establishes a persistent reverse tunnel. This feature cannot be used with Remnawave as the panel.

Expected Behavior

One of the following would resolve this:

  1. Preferred: Add a “reverse proxy user” concept to the squad/inbound system, where a special non-subscribing user entry carries a reverse: { tag: "..." } field that is injected as-is into the target VLESS inbound’s users array, bypassing cleanInboundClients for that entry.

  2. Alternative: Introduce a flag on an inbound registration (e.g. isReverseProxy: true) that causes Remnawave to skip cleanInboundClients for that inbound and pass the raw users array from the config profile directly to xray unchanged.

Environment

  • Remnawave backend: v2.7.4
  • Xray-core: v26.3.27
  • xray-typed: v1.1.1
2

Alternative suggested workaround has drawbacks in my pov also preferred one is somehow not very optimal

It can be done in similar way but with a better execution and customisation options:

  1. User Edit/Create
  2. Add a new toggle as isReverse
  3. Condition check == If TRUE > then >
    4. A new field for Reverse Tag to be typed by Admin (or with a button to randomly generated?)
    5. A new Inbound selection dropdown (like internal squads) in user’s access scope to be used as reverse proxy inbound/outbound
  4. Remnawave injects the related code at runtime to that inbounds related nodes

I think it can be done more easily than other options.

3

There will never be any additional fields for “User.”

I don’t want to make the same mistake other panels made when they linked “flow” to a specific user. In my opinion, such an architecture will cause a huge number of problems in the future. I believe a more correct approach is the same as was implemented for “flow,” which was moved to the same level as “clients.”

It might look something like this, but I haven’t yet decided whether to make a PR to Xray repo: Comparing XTLS:main...kastov:reverse · XTLS/Xray-core · GitHub

4

I haven’t seen that you took initiative to change related matters of it in the core itself.

If it got merged, so yeah otherwise what are the options?

5

Unfortunately, the PR was rejected.

6

So, need to do it with a workaround unfortunately…
